D-SUB Solder Type

No. of Circuits: 9, 15, 25, 37, 50

Current rating: 3.0A AC/DC

Voltage rating: 250 V AC/DC

Contact resistance: 30m ohm.max

Insulation resistance: 5000M ohm.Min

Withstanding voltage: 1000V AC for one minute

Operating temperature range: - 40°C to + 85°C

Insulator: High Temp.Plastic (UL94V-0)

Contact: Copper Alloy Nickel undercoated, Selective gold plated

Finish: Metal Iron with Tin Plated
